—Most technical information involving this project has been omitted to protect confidentiality—

Computer vision has lots of applications when it comes to logistics and on demand ordering services, it can be used to look at photos of drivers licenses to extract their information, or it can be used to verify that the picture of the delivery drop off is successful.

This project used OCR to detect driver registration information to automate the driver registration process. With a single driver license, what would be the best algorithm to go about doing so?

Starting with the basics, first we need to figure out whether or not there is a driver license in the photo to begin with! This requires a basic object detection, and to define the bounding boxes of the driver license within the image to ensure that we have gotten the correct orientation of the driver license.

Popular object detection algorithms include: YOLO, R-CNN, RetinaNet.

Since we know the size of the driver license, we can take the aspect ratio as a tell for if the simple object detection algorithm detects a rectangle in the image, is the rectangle a street sign or is it a driver license? At the beginning we dont care, we just need to make sure the image is in the correct orientation and size in the photo.

To determine if the box in our image is a driver license or just a postcard, this is when we deploy OCR technology. Google Cloud, Azure Computer Vision and AWS Textract all provide great OCR libraries that we can just call and use with our respective accounts. We can also look elsewhere at 3rd party open source OCR libraries, such as Tesseract or EasyOCR are other great options.

Simple OCR call for AZURE:

subscription_key = os.environ["VISION_KEY"]
endpoint = os.environ["VISION_ENDPOINT"]

computervision_client = ComputerVisionClient(endpoint, CognitiveServicesCredentials(subscription_key))
'''
OCR: Read File using the Read API, extract text - remote
This example will extract text in an image, then print results, line by line.
This API call can also extract handwriting style text (not shown).
'''
print("===== Read File - remote =====")
# Get an image with text
read_image_url = "https://learn.microsoft.com/azure/ai-services/computer-vision/media/quickstarts/presentation.png"

# Call API with URL and raw response (allows you to get the operation location)
read_response = computervision_client.read(read_image_url,  raw=True)

# Get the operation location (URL with an ID at the end) from the response
read_operation_location = read_response.headers["Operation-Location"]
# Grab the ID from the URL
operation_id = read_operation_location.split("/")[-1]

# Call the "GET" API and wait for it to retrieve the results
while True:
    read_result = computervision_client.get_read_result(operation_id)
    if read_result.status not in ['notStarted', 'running']:
        break
    time.sleep(1)

# Print the detected text, line by line
if read_result.status == OperationStatusCodes.succeeded:
    for text_result in read_result.analyze_result.read_results:
        for line in text_result.lines:
            print(line.text)
            print(line.bounding_box)

The OCR will just return the raw text data, it might be something like:

Which would be very different then if a post card was detected it would probably show something like:

We can use this differences to tell us what we are looking at in the image and also to detect the correct words. We can use regex to find key words such as address and name and gather the data.

From there we can look for drivers who might share the same driver license, invalid expiry dates or invalid driver license numbers. This project can manually typing and review of a team to just minutes of computer vision review.

As a machine learning engineer, aside from learning and knowing how and when to which algorithms, another aspect of machine learning entirely is computer vision. Computer Vision is almost a completely new subset of machine learning, like going from linear algebra to trigonometry, both are math subjects but both have their own set of equations and formulas that you need to learn. Although similar, being good at linear algebra doesnt mean you are good at trigonometry.

Libraries:

Some of the tools required to make this project work:
Python - Python is a programming language that lets you work quickly and integrate systems more effectively.
OpenCV - OpenCV is a library of programming functions mainly for real-time computer vision. Originally developed by Intel, it was later supported by Willow Garage, then Itseez…
Pandas - Pandas is a fast, powerful, flexible and easy to use open source data analysis and manipulation tool, built on top of the Python programming language.
AWS Sagemaker - Amazon SageMaker is a cloud-based machine-learning platform that allows the creation, training, and deployment by developers of machine-learning models on the cloud. It can be used to deploy ML models on embedded systems and edge-devices.
GCP Vision - The Vision API can detect and extract text from images. There are two annotation features that support optical character recognition (OCR)
Azure VisionAccelerate computer vision development with Microsoft Azure. Unlock insights from image and video content using OCR, object detection, and image analysis.

—This project was live, but to prevent the abuse of private chatgpt keys, it is no longer live—

How we combined a chatbot with a veterinary nutrition textbook to answer “is this food right for my pet?”

When a customer walks into a specialty pet food store, the best staff member they can talk to is one who knows two things simultaneously: what’s on the shelf right now, and why a particular food is actually good for their animal. That’s a hard combination to find in a single person — and it turns out to be an interesting problem to solve with AI.

This post walks through how we built a RAG (Retrieval-Augmented Generation) chatbot for a pet food company that can answer questions like “What should my 8 year old dog with knee joint pain eat?” with real, specific, science-backed answers drawn from the store’s actual inventory.

The Problem with Off-the-Shelf Chatbots

Most e-commerce chatbots fall into generic glorified keyword search — “you typed ‘senior dog’, here are products tagged ‘senior dog’”. They dont have the custom information about what the store holds.

What customers actually need is a system that can connect the nutritional science to the specific products available to buy today. That requires a knowledge base of what is actually good for your furry friend

The architecture centers on a single Pinecone vector index: namespace: nutrition holds the vet nutrition textbook, chunked and embedded using the same pipeline. Each chunk carries metadata so the chatbot can cite its sources precisely.

Species Detection and Metadata Filtering

Before the vector search fires, the query engine does a quick heuristic species detection pass. If the customer mentions “dog,” “puppy,” or “canine,” the inventory search adds a Pinecone metadata filter that restricts results to species: ["dog", "both"]. Same for cats.

The System Prompt Design

Getting ChatGPT to behave correctly in this context required careful system prompt design. A few things that made a meaningful difference:

Explicitly labeling the two source types and instructing ChatGPT to cite them separately — product recommendations with prices and links, nutritional claims with chapter/section/page references.

A hard rule against medical diagnoses. The chatbot will explain nutrition science, but for anything that sounds like a health condition, it defers to the vet. This is both legally sensible and practically correct: a customer whose cat has kidney disease needs a vet, not a chatbot, making the primary call. The chatbot is not supposed to replace a real vets advice, and its important that we make that distinction clear.

Sample Prompt

Writing simple prompts, to ensure that the model is staying on topic

You are a helpful and informative chatbot that answers questions based on a speech or text passage.
Respond in a complete sentence and make sure that your response is easy to understand for everyone.
Maintain a friendly and conversational tone. If you do not know the answer, then respond with 'I don't know.' Do not assume or try to guess.
Provide proof based on the documents shared.

It’s not a replacement for an expert staff member. But it’s available at 2am, it never gets tired, and it doesn’t forget what it read in the textbook.

What’s Next

A few natural extensions from here: Personalization. Storing a customer’s pet profile (species, breed, age, known sensitivities) would allow the chatbot to pre-filter and weight results without the customer having to repeat themselves every conversation.

Including the specific information regarding the store, and then helping place the order all within a chatbot.

Libraries:

Some of the tools required to make this project work:
Python - Python is a programming language that lets you work quickly and integrate systems more effectively.
ChatGPT - ChatGPT is your AI chatbot for everyday use. Chat with the most advanced AI to explore ideas, solve problems, and learn faster.
LangChain - LangChain provides the engineering platform and open source frameworks developers use to build, test, and deploy reliable AI agents.

—Most technical information involving this project has been omitted to protect confidentiality—

Fraud detection and prevention is a necessary step for all applications, businesses and services. From food delivery, insurance to sports and crypto apps, all need layers of security to ensure that users are safe and to catch fraudulent activity when it happens.

In the case of transportation and logistics apps, the fraud detection is needed to ensure drivers and users are not making multiple accounts, are not making fraudulent orders or drivers trying to scam users on our platform. Traditionally, this type of work was manually conducted, using CSVs and pivot tables, complex operations of comparison to determine if users had shared characteristics with other users, or manually go through the flow of driver behaviour to determine the fraud.

Utilizing deep learning, we can now determine if users or drivers are trying to commit fraud without having to manually scan through hundreds of thousands of users. Looking deeper into the user and driver behaviour features, to find patterns that normally humans would have trouble discovering on our own. Utilizing deep learning feature selection to narrow down the most important features in detecting fraud, with techniques such as PCA, as well as look for features that users might have in common.

Simple fraud detection starts with looking at banking information, if payments get transfered, when users or drivers make silly mistakes of misusing the application.

Once we have established a baseline for fraudsters, we can use more complex techniques and algorithms such as feature engineering to find more drivers and users we fit the fraudster profile.

A simple random forest classifier supervised model

from sklearn.model_selection import train_test_split
from sklearn.ensemble import RandomForestClassifier

# Splitting the data into training and testing sets
X_train, X_test, y_train, y_test = train_test_split(X, y, test_size=0.2, random_state=42)

# Initializing the Random Forest classifier
clf = RandomForestClassifier()

# Training the classifier
clf.fit(X_train, y_train)

# Predicting on the test set
y_pred = clf.predict(X_test)

Looking for users and drivers that attempt to place orders for free. Risk scoring to look for the frequency, location, and past behavior.

Looking for relationships between accounts, users and devices to find unusual connections and clusters. As well as identity verification, to check if individuals are who they claim to be.

The data was then run through exploratory data analysis: simple correlation operations to determine the feature with the greatest correlation to fraud detection.

Fraud detection

Libraries:

Some of the tools required to make this project work:
Python - Python is a programming language that lets you work quickly and integrate systems more effectively.
OpenCV - OpenCV is a library of programming functions mainly for real-time computer vision. Originally developed by Intel, it was later supported by Willow Garage, then Itseez…
Pandas - Pandas is a fast, powerful, flexible and easy to use open source data analysis and manipulation tool, built on top of the Python programming language.
AWS Sagemaker - Amazon SageMaker is a cloud-based machine-learning platform that allows the creation, training, and deployment by developers of machine-learning models on the cloud. It can be used to deploy ML models on embedded systems and edge-devices.

Long Short Term Memory (LSTM) model was developed to monitor short term power output predictions from 4 hour ahead to 6 hours ahead. This research paper demonstrated a unique approach of utilizing nearby publicly available meteorological data to predict renewable energy power output that could potentially be used for wind and solar farm scheduling to prevent curtailment of clean energy.

This paper was written for completion of my Masters major research project under Toronto Metropolitan University and as a result the paper cannot be shared publicly without explicit permission from the University. It was written in Python with Pandas, Numpy, Tensorflow and other supporting libraries.

Questions to be Answered:

1. Can all of Ontario’s power demands be met with renewable energy?

2. What are the key features for determining renewable energy?

3. What would be the best algorithm choice to predict renewable energy?


The dataset used was collected from the [Independent Electricity System Operator] and the [NASA Solar Satelitte dataset.]

The dataset made up of approximately 50 meteorological features total over a 4 year time period. Notable features such as wind speed, solar radiation, air temperature, dew point temperature and humidity all played a role in determining total solar and wind power generation capacity.

The data was then run through exploratory data analysis: simple correlation operations to determine the feature with the greatest correlation to wind power. The data was also cleaned and outlier values were either removed or replaced with average values.

The Long Short Term Memory LSTM deep learning algorithm is trained on 3 years worth of data, with the 4th year being the validation/ testing year. This results in a 75% training, 25% testing split. The benefit of using LSTM networks over a traditional mathemetical model such as the ARIMA (Autoregression Integrated Moving Average), is that there doesnt need to be a processing step to remove trends and seasonality.

The Long Short Term Memory algorithm requires a number of timesteps, also known as an input window size. To determine how many past values of the series will be used for the current prediction. For example, if i wanted to predict 2 pm, should consider weather at 1 pm, 12 pm, and 11 am as my past values, meaning my window size is 3 hours.

Here we can see the output result for the solar farm, seperated by season. The algorithm is predicts the next 4 hours ahead with relative certainity. The wind farm is also predicted and both results are shown below.

Additional work would be to include more weather variables and try utilizing a CNN model to the algorithm before utilizing the LSTM.

Libraries:

Some of the tools required to make this project work:
Python - Python is a programming language that lets you work quickly and integrate systems more effectively.
Scikit-Learn - An open source Machine learning library in python used for data preprocessing, classification, regression, etc…
Pandas - Pandas is a fast, powerful, flexible and easy to use open source data analysis and manipulation tool, built on top of the Python programming language.
Jupyter Notebooks - web-based interactive development environment for notebooks, code, and data.

Vector embeddings are essentially converting text or other forms of unstructured data such as audio and images into a high dimension matrix. This high dimensional space is known as an embedding, and can be used to increase the speed and accuracy of search results, as compared to semantic search. In a vector database, queries that have similarities are put together based on similarity, just like K nearest neighbours which makes them much faster to find compared to relational databases. With the ongoing development of technologies such as ChatGPT and other Large Language Models, there is an increasing need for an upgrade from the data base side to match the speed of the models. The enormous number of attributes and features that the model has to draw insights for is endless and take time and computing power to query searches. To solve this issue, using a specialized database that can provide a vector embedding and essentially group the data by semantic meaning, like a K nearest neighbour vector match to draw insights quickly and more accurately than a semantic database.

This project utilized the Climate policy radar database, which consisted of over 4000+ policies and papers that were written regarding climate.

As a researcher for example, almost always when you have a thesis or journal paper or novel idea, then you have to find background articles, papers that other people wrote that are similar but not exactly the same. This can be difficult to find as your idea is novel and assuming you are the first one to write a paper about it, it would not show up on a typical search engine, This is where vector embedded search comes in, if you were to search your paper details, you would be able to find the 10+ journal papers that have the relative closeness of your paper, and reference them much faster.

Objectives

• Build a database based on the Climate Radar Policy
• Create vector embeddings for the climate radar policy features
• Write a python flask search application to query and display results back to users

It was written in Python, using Docker with Weaviate and other supporting libraries.

A docker container was created for all its dependencies. The dataset used was collected from the [Climate Policy Radar]

The dataset made up of approximately 4000+ journals, laws and papers totaled over a 4 year time period. Notable features include, name, summary, category, sector, language, country of origin and outcome of the policy.

class_obj = {
        "class": "Article",
        "description": "Information regarding Climate Policy",
        "properties": [
            {
            "name": "Document_title",
            "dataType": ["string"],
            "description": "Document Title",
            },
            {
            "name": "Family_summary",
            "dataType": ["string"],
            "description": "Document Summary",
            },
            {
            "name": "Category",
            "dataType": ["string"],
            "description": "Document Category",
            },
            {
            "name": "Sectors",
            "dataType": ["string"],
            "description": "Document Sector Topics",
            },
            {
            "name": "Keywords",
            "dataType": ["string"],
            "description": "Document Multiple Keywords",
            },
            {
            "name": "Responses",
            "dataType": ["string"],
            "description": "Document Publish Response",
            },
            {
            "name": "Language",
            "dataType": ["string"],
            "description": "Written Language",
            },
            {
            "name": "Geography",
            "dataType": ["string"],
            "description": "Country of Origin",
            }
        ]
    }

The data was then run through exploratory data analysis: simple data cleaning and text organizing then uploaded to the schema as well.

Flask application

The flask application is connected to the Weaviate Client.

Here the Weaviate nearText operator is used, to search for text that has the closest semantic meanings to the query that the user searched for. The response from the search query will include the closest objects in the climate policy class. The output response is then taken as the name, summary and details of the selected journal article.

Lastly the flask app front end and back end is created. Firstly the backend for POST requests from Weaviate is created and the search function to return the results from the client and render the page.

The index.html file

The search results.html file

The final website functionality

With relative ease of use, I have created a fully functional vector embedded search engine, for any database files.

This application is not limited to climate policy radar search engine data, the possibilities such as finding shoes that are similar to the ones you own, finding animals that look alike each other. The extensive possibilities for these technologoies with large language models such as chatGPT make it endless.

Libraries:

Some of the tools required to make this project work:
Python - Python is a programming language that lets you work quickly and integrate systems more effectively.
Weaviate - Weaviate is an open-source vector database. It allows you to store data objects and vector embeddings from your favorite ML-models, and scale seamlessly into billions of data objects.
Docker - Docker is a platform designed to help developers build, share, and run modern applications.

Museum curators spend millions of dollars every where to determine fake paintings from the real ones. Teaching curators to spot fake paintings and determine real stroke marks has always been a major challenge even with carbon dating. Utilizing computer vision to devise a method to compare painting stroke types or to perform some preliminary sweeps before a human will need to go in and look at the paintings, similar to applicant tracking systems and filtering resumes and cover letters before they are ever seen by a real person.

Some questions that needed to be answered were:

1. Are there methods to infer what paint brush was used for a specific paint stroke?
2. What is the best way to tell between two brush strokes with the exact same colour, and the exact same brush?

Starting with creating a pipeline to set up data base and data segmentation. Developing a dataset of paintings and individual paint strokes for comparison.

Multiple comparison scores are developed using OpenCV2. Colour matching, skeletoning, and texture detection are all run through the library to compare two paint strokes. Produced visual reports and comparison data to give an overall score on painting stroke types.

Skeletionization of stroke types using basic morphological operations

Performing thresholding, first converting an image to grayscale then into a binary image. Choosing a specific threshold, and pixels with values greater than the threshold will be white (255), and similar will be converted to black (0).

With thresholding only, there are parts of the image that might not be what we are looking for. In the example above notice that there are pixels between the cell images that we are not interested in. To remove these unwanted pixels, running basic morphological operations on the thresholded images.

Dilating and Erosion:

Dilating adds pixels to the boundaries of objects while erosion removes pixels on the object boundaries.

Performing simple morphological operations after thresholding to get skeletonized images of paint strokes. Then running comparison of the skeletonized images by pixel values to compare paint strokes.

This was one of the many techniques used to compare images. Multiple additional processes done to compare the strokes provided a numerical percentage value of likeness. The full repository is private for company usage but this was simply an example of the operatons completed.

Potential future work is the utilization of GANs to create and mimic the paintings, then have the algorithm compare between the original paining the GAN created painting.

Libraries:

Some of the tools required to make this project work:
OpenCV2 - An open source computer vision and machine learning software library.
Scikit-Learn - An open source Machine learning library in python used for data preprocessing, classification, regression, etc…
Jupyter Notebooks - web-based interactive development environment for notebooks, code, and data.

This paper advances and builds on existing knowledge to introduce a novel solution with an already existing algorithm for detecting a traffic sign and estimate the boundary within and input image. Estimating the boundary of traffic signs within an image and classification of a shape class prediction, solved using a CNN. The proposed algorithm and method using a U-Net CNN is compared aganist existing CNN methods in terms of computational time, and accuracy of detection.

Utilizing the UNet algorithm that is traditionally used for Medical Imaging, and utilizing it for image segmentation of traffic sign data. The Data sets were gathered from Kaggle opensource datasets and the training was done off a jupyter notebook.

The model was trained using tensorflow, building the model and tweaking the model configurations to maxmize model performance. I utilizied a Rectified Linear Unit Activation (ReLu) in between Convolution layers then trained for only 30 epochs as the model would reach reach maximum accuracy relatively quickly.

More details about the model can be found in the paper.

Research Project Final paper:

Libraries:

Some of the tools required to make this project work:

MySQL - MySQL is a domain-specific language used in programming and designed for managing data held in a relational database management system.
TensorFlow - TensorFlow is a free and open-source software library for machine learning and artificial intelligence. It can be used across a range of tasks but has a particular focus on training and inference of deep neural networks
Jupyter Notebooks - web-based interactive development environment for notebooks, code, and data.
